Negative Pressure Ureteral Access Sheath
Specification(Fr/Ch): 10/11/12/13/14
O.D (mm): 3.3/3.7/4.0/4.3/4.7
Effective length S1 (mm): 355/450
Description
Negative Pressure Ureteral Access Sheath
For Single Use are available with outside diameters ranging from 10 to 14
French and lengths ranging from 35.5 to 45 centimeters. These devices are available in a single lumen configuration
and include a sheath and a dilator. The dilator component includes a tapered and a hydrophilically coated distal tip.
The product is used to create an easy access for endoscopy and other instruments to enter the urinary tract during endoscopic urological surgery.
|
Model |
suction sheath |
|||||
|
Specification Fr/Ch |
sheath introducer |
dilator |
||||
|
outer diameter D1 (±0.1 mm) |
Min ID d1 (mm) |
S1(mm) |
Max OD D2(mm) |
Min ID d2 (mm) |
S2 (cm) |
|
|
10 |
4.0 |
3.3 |
355/450 |
3.3 |
1.0 |
2.5 |
|
11 |
4.5 |
3.7 |
355/450 |
3.7 |
1.0 |
2.5 |
|
12 |
4.8 |
4.0 |
355/450 |
4.0 |
1.0 |
2.5 |
|
13 |
5.0 |
4.3 |
355/450 |
4.3 |
1.0 |
2.5 |
|
14 |
5.3 |
4.7 |
355/450 |
4.7 |
1.0 |
2.5 |
